ISS018-E-11127
Browse image
Resolutions offered for this image:
1000 x 664 pixels 540 x 360 pixels 720 x 480 pixels 3072 x 2098 pixels 640 x 437 pixels

MAP LOCATION
latitude/longitude of image
Spacecraft nadir point: 41.3° N, 109.3° W

Photo center point: 40.1° N, 109.0° W

Nadir to Photo Center: South

Spacecraft Altitude: 186 nautical miles (344km)
Click for Google map
IMAGE DETAILS
features and other details
CAMERA INFORMATION
information about camera used
ALL DOWNLOAD OPTIONS
additional formats
Width Height Annotated Cropped Purpose Links
1000 pixels 664 pixels No Yes NASA's Earth Observatory web site Download Image
540 pixels 360 pixels Yes Yes NASA's Earth Observatory web site Download Image
720 pixels 480 pixels Yes Yes NASA's Earth Observatory web site Download Image
3072 pixels 2098 pixels No No Download Image
640 pixels 437 pixels No No Download Image
Other options available:
Download Packaged File
Download a Google Earth KML for this Image
View photo footprint information
Image Caption: Raven Ridge, Colorado

An important way to unravel the Earth's history is to find and study old rocks that have been turned up and exposed on the surface through the Earth's tectonic activity. At Raven Ridge (image center, left to right), which extends across the Colorado-Utah border, geologists can walk across successive layers of rock deposited approximately 54-50 million years ago during the Eocene Epoch--approximately 10-15 million years after the dinosaurs went extinct.

The sedimentary layers at Raven Ridge were originally deposited as flat-lying beds in an ancient lake known as Paleolake Uinta, and later they were tilted by tectonic forces. The tilted beds are visible in this astronaut photograph as hard, erosion-resistant ridges of tan, buff, and white rocks (freshwater limestones), with less resistant layers (mudstones and shales) forming valleys between ridges.

A prominent topographic break in the ridgeline, Mormon Gap, provides road access across the ridge. To the northwest of the gap, dark brown alluvial deposits (sand and gravel carried by moving water) extend southward from the crest of the ridge. These deposits likely cover a pediment--a flat, sloping surface of eroded bedrock that extends outward from a mountain front.

The rocks and fossils at Raven Ridge indicate that during the time when they were created, the area was covered in tropical forests that were filled with the early ancestors of modern primates, horses, and deer (among other animals).
