ISS037-E-5104
Browse image
Resolutions offered for this image:
1000 x 580 pixels 540 x 313 pixels 720 x 480 pixels 4256 x 2832 pixels 640 x 426 pixels

MAP LOCATION
latitude/longitude of image
Spacecraft nadir point: 51.8° S, 74.1° W

Photo center point: 49.9° S, 73.3° W

Nadir to Photo Center: North

Spacecraft Altitude: 228 nautical miles (422km)
Click for Google map
IMAGE DETAILS
features and other details
CAMERA INFORMATION
information about camera used
ALL DOWNLOAD OPTIONS
additional formats
Width Height Annotated Cropped Purpose Links
1000 pixels 580 pixels No Yes NASA's Earth Observatory web site Download Image
540 pixels 313 pixels Yes Yes NASA's Earth Observatory web site Download Image
720 pixels 480 pixels Yes Yes NASA's Earth Observatory web site Download Image
4256 pixels 2832 pixels No No Download Image
640 pixels 426 pixels No No Download Image
Other options available:
Download Packaged File
Download a Google Earth KML for this Image
View photo footprint information
Image Caption: Upsala Glacier Retreat, Patagonia Icefield, 2002-2013

Note: This caption refers to the image versions labeled "NASA's Earth Observatory web site".

This astronaut photograph highlights the snout of the Upsala Glacier (49.88S 73.3W) on the Argentine side of the Southern Patagonian Icefield. Ice flow in this glacier (white mass, image right) is from the north (right). Dark lines of rocky moraine within the ice give a sense of the slow ice flow from right to left. A smaller side glacier joins Upsala at the present-day ice front--the wall from which masses of ice periodically collapse into Lake Argentino. In this image the 2.75 km-long wall casts a thin, dark shadow. The surface of Lake Argentino is whitened by a mass of ice debris from a recent collapse of the ice wall. Larger icebergs that have calved appear as white dots on the lake surface at image left.

Remotely sensed data, including detailed astronaut images such as this, have recorded the position of the ice front over the years. Even though the ice actually flows slowly southward, comparison of this October 2013 image with older data (not shown) indicates that the ice wall of the glacier has moved backwards--upstream--an average of 3.6 km since early 2002. This so-called "retreat" is believed by scientists to indicate local climatic warming in this part of South America. The warming not only causes the ice front to retreat but more importantly, causes overall thinning of the glacier ice mass, as a study of 63 glaciers in Patagonia has shown is now a general trend (Rignot et al. 2003). Ice-front retreat is now known to be related to volumetric loss due to melting.

Water color is related to glacier flow. Lake Argentino receives most of the ice from the glacier and thus also receives most of the "rock flour" (rocks ground to white powder by the ice scraping against the rock floor of the valley) from underneath the glacier. Glacial flour turns the lake water a gray-green hue in this image. The darker blue of the smaller lakes (image bottom) indicates that they are receiving much less rock flour.

Rignot E, Rivera A, and Casassa G, 2003, Contribution of the Patagonia Icefields of South America to sea level rise. Science 302:434 - 437.
